The 1200mm stainless steel glass door pull handle page supports OEM project enquiries for long entrance pulls used in lobby, villa and commercial glazing schedules. Qingdao Gleam Hardwares reviews the requested long-format configuration around its mounting layout, material, appearance and shipping protection. The 1200 mm overall length is available for made-to-order production, with standard or custom mounting centers. The photographs show the long-handle style family.
Compare all glass door pull handle styles and select the configuration for your project.
Common Sizes and Custom Options
These are made-to-order production options. Special lengths, mounting centers and profiles can be customised.
| Specification | Production options |
|---|---|
| Overall length | 1200 mm |
| Mounting centers (C-to-C) | 1040 mm production option; other hole pitches made to your drawing |
| Round tube diameter | 25 or 32 mm |
| Glass thickness | 8, 10 or 12 mm with the matching fixing kit |
Specify overall length and C-to-C separately. Confirm the selected length, mounting centers, glass holes and fixing kit together on the order drawing.
Specify a 1200mm Long Stainless Steel Glass Door Pull Handle
A long visible grip can be a defining feature of an entrance, but overall length alone does not define a workable assembly. Send the mounting-center distance, end overhangs, projection, door thickness and the permitted fixing arrangement. On paired leaves, confirm alignment of both sets against the same door schedule.
| Long-handle specification | Project requirement to confirm |
|---|---|
| Requested overall length | 1200mm long stainless steel glass door pull handle; confirm that 1200mm means total length, not hole pitch |
| Mounting centers and supports | C-to-C distance, mounting-post positions and any additional support requirement subject to drawing review |
| Grip section | Round tube diameter and wall thickness; 32mm diameter requests require separate confirmation |
| Door interface | Glass type/thickness, prepared holes, fastener system and other door hardware |
| Material specification | Requested SS304 or a separately reviewed 316 stainless steel option for the project environment |
| Surface | Polished or brushed satin sample, grain direction and visible joint treatment |
| Set definition | Paired grips for one door leaf, agreed mounting kit and spare components if required |
| Export packing | Protection for ends, tube surfaces and projecting posts; agreed carton construction and labeling |
| Wholesale MOQ / schedule | Confirmed from the long-format specification, quantity and packing plan |
316 Stainless Steel Exterior Glass Door Handle for Coastal Projects
If the entrance is exposed to coastal salt or other aggressive conditions, include that information in the request for a 316 stainless steel exterior glass door handle. Material selection must address the complete visible and fixing assembly, finish, location and cleaning plan. Confirm grade and any required verification records before production.
Stainless steel is not immune to corrosion. Exposure and surface conditions influence its behavior, as described in Outokumpu’s atmospheric-corrosion guidance. This general material guidance is not a test report or a service-life claim for this handle.
Protect the Finish Between Workshop and Job Site
Long handles create different handling needs from compact shower pulls. Review separation between metal surfaces, protection for mounting posts, carton stiffness and how complete pairs are identified. Include the shipping mode and destination so the packing discussion is based on the actual route and handling plan.
| Packing decision | Information to agree | Buyer value |
|---|---|---|
| Individual protection | Grip sleeves or wrapping, protected ends and isolated fittings | Helps reduce cosmetic damage and repacking |
| Pair identification | Door reference, finish, drawing revision and complete-set count | Makes site allocation easier |
| Carton size and weight | Final packed dimensions and gross weight before shipment | Supports landed-cost and receiving planning |
| Service components | Separate spare fixing pack if ordered | Helps project teams manage maintenance parts |
Procurement Example: Matching Lobby Entrances
For example, a contractor fitting a pair of tall lobby doors can submit one door schedule with the intended 1200mm total length, measured mounting centers and finish reference. The quotation can then identify two complete paired sets, their fixing kits and any requested spare parts. This is an illustrative purchasing workflow, not a completed customer project.
For a distributor, retaining that approved configuration makes a later replacement enquiry easier to identify. It also gives the sales team a precise specification to discuss rather than relying on long, heavy-duty or luxury as the only descriptions.
Need a Different Handle Configuration?
- Need a shorter matching entrance pull? Compare commercial ladder pull sizes.
- Replacing a door with fixed holes? Use the custom C-to-C series.
- Coordinating a black hardware package? Review the matte black H-style range.
View the full handle selection table for a side-by-side comparison.
Long Entrance Pull FAQ
Is 1200mm the mounting-center distance?
Only if your drawing specifies it that way. This page uses 1200mm as the requested overall length; the hole pitch is a separate dimension.
Does a long pull need more than two mounting posts?
The support arrangement must be reviewed against the construction and application. Do not assume it from a product photograph.
Can this be supplied for a wooden main entrance door?
Send the door substrate and thickness for a separate fixing-kit review. A glass fixing kit is not automatically suitable for wood.
Can you supply a material test report?
State the required record or testing scope in the enquiry. Availability, cost and acceptance criteria must be agreed for the quoted order.
Request a Long Entrance Handle Quote
For a 1200mm long stainless steel glass door pull handle quotation, send the full drawing, door schedule, material and finish, complete-set quantity and shipping destination.
Technical Guides for Your Specification
- Measure mounting centers and glass-door clearance before selecting the length and fixing kit.
- Compare SS304 and SS316 for the installation environment before setting the material and finish schedule.
