Miniature Bearings in Bulk and Roller Assemblies

Qingdao Gleam Hardwares supplies miniature ball bearings in bulk and finished roller assemblies for hardware importers, door and window system suppliers, equipment builders and skate brands. The range includes shielded and sealed bearing cores, plastic bearing rollers and metal track rollers with controlled grooves, flanges or extended hubs.

Start by identifying what you need to purchase: a bare bearing, an existing finished wheel or a roller developed from a drawing or sample. A bearing code defines the core; it does not define the finished wheel diameter, track contact or complete mounting geometry.

Compare the standard bearing and roller options below, then use the dimension and track guides to prepare your enquiry. For made-to-order dimensions, ring features or application specifications, open the dedicated custom and non-standard deep groove ball bearing series. Common bearing dimensions are identification references. Confirm the full suffix, material, lubrication, fit and application requirements for the ordered part.

Miniature Bearing Bulk Supply for Importers and OEMs

Compare standard miniature bearings for hardware assembly, replacement-parts distribution and private-label programmes. For a miniature bearing bulk order, list each complete code and suffix, material, lubricant, quantity and packing format so the quotation covers the intended configuration.

For mixed-model enquiries, send a model-by-model quantity list. Free samples are available; sample selection, order requirements and shipping arrangements are confirmed with your enquiry. For a finished wheel, add the complete roller dimensions and mounting details.

Custom & Non-Standard Deep Groove Bearings

For door and window systems, special-size miniature bearings or machinery OEM projects, compare the custom bearing subcategory. It separates three RFQ routes so buyers can provide the correct drawing, sample, application and quantity.

RFQ help: custom bearing specification checklist · door and window sample-to-drawing guide.

Choose the Bearing or Roller for Your Project

Product range Buying requirement Key selection difference
608 skate-bearing sets Skate brands and wheel assemblers 8 × 22 × 7mm core; specify ZZ or 2RS, lubrication, spacer fit and pack count.
608-2RS sealed door-roller core Sealed bearing for an existing roller 8 × 22 × 7mm reference; confirm seal arrangement and finished wheel separately.
Door and window plastic rollers Select an existing roller construction Match polymer, track profile, finished diameter, width and axle.
Custom plastic bearing roller Drawing or sample development Define finished geometry, polymer/coating, bearing retention and sample approval.
Dual-groove metal track roller A rail with two matched contact paths Control groove pitch, radius, finished width and rail section.
Flanged and extended-hub roller Axial location in door hardware Confirm flange diameter, hub projection, shoulders and bracket clearance.
608ZZ bearing wholesale supply Hardware and general roller assemblies 8 × 22 × 7mm reference; metal shields, material and clearance specified separately.
605ZZ–608ZZ miniature range Compact mechanisms and RC model programmes Choose each full code and suffix; do not use one size across the range.
Multi-groove metal pulley Several rail contacts or ribs Supply groove count, spacing, depth and complete section drawing.
625ZZ bearing supplier for pulley cores Small bearing for pulley manufacture 5 × 16 × 5mm reference; finished pulley dimensions are additional.

Catalogue Reference: Dimensions, Load Ratings and Speed

The table below uses published NSK catalogue values as a consistent reference for preliminary model comparison. It is not a universal performance guarantee: bearings with the same basic designation can use different internal designs, materials, seals, grease and clearances.

Model d × D × B (mm) Basic dynamic load C (kN) Basic static load C0 (kN) Grease limiting speed (rpm) Oil limiting speed (rpm)
605 5 × 14 × 5 1.33 0.505 40,000 50,000
625 5 × 16 × 5 1.73 0.670 36,000 43,000
606 6 × 17 × 6 2.26 0.835 38,000 45,000
626 6 × 19 × 6 2.34 0.885 32,000 40,000
607 7 × 19 × 6 2.34 0.885 36,000 43,000
608 8 × 22 × 7 3.30 1.37 34,000 40,000
6000 10 × 26 × 8 5.05 1.97 30,000 36,000

Reference boundary: grease and oil speeds above are catalogue comparison values for the listed manufacturer configuration. Contact seals, grease type, fit, load, temperature and clearance can reduce permissible speed. Final load ratings and speed limits follow the approved sample and production data sheet.

Official technical references: NSK Miniature Ball Bearings catalogue and NSK rolling-bearing product tables.

608 and 6000 Bearing Interfaces for Skate and Scooter Wheels

Many skate and scooter wheel programmes use a 608-format bearing seat, while selected larger-wheel designs use a 6000-format interface. The two sizes are not interchangeable: 608 uses an 8 × 22 × 7 mm nominal envelope and 6000 uses 10 × 26 × 8 mm. Confirm the wheel bearing seat, axle, spacer and total hub width before choosing either model. For confirmed 608 programmes, see our 608ZZ wholesale bearing page; for a 6000 project, quote the complete suffix and wheel interface with the category enquiry.

Typical Bearing Configuration Options

These are common sourcing options, not a claim that every combination is stocked. The final specification is confirmed by model, application, sample and purchase order.

Selection item Typical options What must be confirmed
Material GCr15 / 100Cr6 / SAE 52100 / SUJ2 equivalent bearing steel; stainless-steel options Exact grade, corrosion environment, ring/ball construction and acceptance documents
Precision ABEC 1 / ISO Normal (commonly P0); ABEC 3 / ISO 6 (P6); ABEC 5 / ISO 5 (P5); higher precision by project ABEC describes dimensional and running accuracy; it does not by itself guarantee load, life or low noise
Noise and vibration Standard or low-noise/low-vibration grade Agreed measurement method, frequency band and limit; do not infer noise grade from ABEC alone
Radial clearance C2, CN/C0, C3; manufacturer-specific miniature clearance ranges Shaft/housing fit, interference, speed and operating temperature
Closure Open, Z, ZZ/2Z, RS, 2RS and low-friction seal options Dust or moisture exposure, grease retention, starting torque and permissible speed
Lubrication and temperature General-purpose, low-temperature, high-temperature/high-speed, low-torque or low-noise grease Seal, grease, cage, speed, duty cycle and actual operating-temperature range
Packaging Tube, tray, individual box, industrial bulk packing, neutral or OEM labels/cartons Pieces per inner pack and carton, rust protection, label, barcode and carton mark

Sample Comparison and Three-Quantity Quotation

Free standard samples are available for dimensional, closure and application comparison. Buyers may request a size comparison from selected 605/606/607/608/625/626/6000 models, an Open/ZZ/2RS closure comparison, or application-matched samples for wheels, rollers and pulleys. Sample combination, quantity, availability and shipping arrangement are confirmed before dispatch; special grease, noise grade, marking or non-standard dimensions may require separate preparation.

Quotation quantity Suitable for Pricing basis
2,000 pcs Trial order or initial application validation Model, closure, material, precision/noise, grease and packing
10,000 pcs Regular bulk purchasing Repeat-order specification, labels and carton configuration
50,000 pcs+ Volume purchasing and OEM packing review Forecast, production lot, marking, packaging and trade term

These are quotation comparison points, not a universal MOQ or fixed public price. Technical documents are provided on request after the model and configuration are confirmed: available dimensional drawing, specification sheet and tolerance information can be reviewed for purchasing or assembly. No unverified CAD file is presented as an instant download.

Request Samples, 2D Data and 2K / 10K / 50K Pricing · Discuss the bearing list on WhatsApp

Specify the Finished Roller Separately

For plastic or metal rollers, add finished outside diameter, total width, bore or sleeve, groove radius/angle, groove pitch, flange diameter and hub projection. Send the matching rail and bracket section. Nylon, POM, PU, rubber or metal running surfaces must be evaluated against the actual track, load and environment.

Bearing and Track Selection Guides

Plastic Tube and Box Packing for Bulk Bearing Orders

Specify the bearing code, pieces per tube or inner box, label and export packing requirements with your quantity list. The photos below show available packing formats for discussion; the ordered model and pack count are confirmed in the quotation.

Ball bearings stacked in five transparent plastic tubes with an open packing box
Tube and box packing example for bulk bearing orders.
Metal-shielded ball bearings beside two transparent plastic packing tubes
Shielded bearing and plastic tube packing reference.

For repeat orders, agree the full code, material and closure, inner-pack quantity, batch identification and carton label with the approved sample.

Request a Bearing or Roller Quotation

Send the full bearing code, measured dimensions, drawing or sample photos, application, rail and mounting details, expected quantity and packing requirements. For custom assemblies, agree the sample and inspection criteria before production.

Request Bearing and Roller Drawing Review
